Gravity Hammer Swing Detection

A method for detecting Gravity Hammer swings using weapon rotation and simulated ammo depletion.

Cover image

Because Forge lacks an On Weapon Fired node and cannot directly track the charge amount of energy weapons, detecting a Gravity Hammer swing requires a combination of rotation monitoring and ammo manipulation.

Detection and Simulation Logic

Hammer swing implementation
The implementation can be used to track hammer swings during active gameplay.

Rotation-Based Swing Identification

The system monitors the rotation of the player's equipped weapon every tick. A swing is identified when the X value of the weapon's rotation exceeds 120. This threshold is effective because the hammer swing causes a more drastic change in weapon rotation than other available poses.

The Gravity Hammer swing detection in action, as well as a showcase of the scripting.

Ammo Depletion and Melee Validation

To track whether a swing results in a hit while maintaining the hammer's intended ammo capacity, the following logic is applied:

  • The player's secondary weapon is dropped.

  • The hammer's ammo is emptied and then refilled to 10%, which is the method used to reduce the ammo of a single weapon.

  • The secondary weapon is returned to the player.

  • If a hit occurs, the On Weapon No Ammo event gets triggered. A number variable is then used to restore the desired amount of ammo and decrement the value for the next swing.

  • If the number variable is not modified within 1 second, the swing is treated as a dummy melee hit (pressing melee button instead of fire button), and the charge is restored.

Customization and Constraints

Modifying Swing Capacity

Users can artificially increase the number of available swings by adjusting the amount by which the number variable is decremented. For instance, changing the decrement from -10 to -5 allows for a total of 20 swings instead of the standard 10.

Known Limitations

  • Vehicle Interaction: Swinging the hammer while moving forward in a vehicle can cause the detection to break.

  • Ammo Pickup Issues: Picking up ammo from a dropped weapon of the same type can cause issues, as the system cannot reliably detect the amount of ammo acquired to update the hammerAmmoRemaining variable.
